Photos may include other items sold separately.
Flex Cine RGBW Mat (1' x 1')
Quantity:
Pick up available at {{ location name }}
Usually ready in 24 hours
Flex Cine RGBW Mat (1' x 1')
Westcott HQ
Pick up available, usually ready in 24 hours
1425 Holland Road
Suite B
Maumee OH 43537
United States
- Requires existing Flex Cine DMX Dimmer #7580. Not compatible with Flex Cine Dimmer #7582.
- Adjustable full visible color spectrum lighting
- Water-resistant IP64 1' x 1' mat fits into tight spaces
- Flexible and pliable design allows for dynamic light spread up to 360-degrees
- Color accurate up to 98 CRI and 99 TLCI
- Powerful output up to 1800 lux at 1 meter
- Backed by an unmatched lifetime limited warranty
- Lightweight, compact design ideal for travel and storage
- Corners equipped with powerful magnets and grommets
- Incorporated Mat Sensing Technology for customized dimmer controls and powering
- Wide range of light modifier and mounting options available
- Heavy-duty cable with TE-9 pin connector attaches to Flex Cine DMX Dimmer (sold separately)
- Requires AC Adapter or 26V V-Mount Battery. Product will not operate on 14.4-14.8V V-Mount Battery.
In The Box:
- 1 x Flex Cine RGBW Mat (1' x 1')
Lighting
- Beam Angle
- 140-360°
- Flicker Free
- Yes (To 960 fps)
- Mat Cooling
- Passive
- Mount Type
- Flex Mounting System
- Panel Size
- 1' x 1'
- IP Code
- IP-64
- Operating Temp.
- 140°F/40°C (Max.)
- Mat Warranty
- Limited Lifetime
Photometric Data
- CCT
- 3200 – 5600K
- CRI
- 92 - 98
- Foot-Candles (1m)
- 157.6 / 167.5
- Foot-Candles (3m)
- 18.2 / 19.1
- Foot-Candles (5m)
- 6.6 / 7.1
- Lux (1m)
- 1696 / 1803
- Lux (3m)
- 196 / 206
- Lux (5m)
- 71 / 76
- TLCI
- 99 / 94
Electrical
- Voltage
- DC 21V
- Watts
- 55W
- Input Power
- DC 24V
- Cable Type
- 9-wire AWG 18
- Cable Connector
- TE 9-pin connector, Female
- IP Code
- IP-64
- Operating Temp.
- 140°F/40°C (Max.)
- Power Type
- AC/DC
- Certifications
- CE, FCC, UL
Battery
- Battery Voltage
- 26V
- Battery Removable
- No
General
- Product Dimensions
- 12.0 × 12.0 × 0.5 in. (30.5 × 30.5 × 1.3 cm)
- Item Weight
- 1.3 lbs. (0.6 kg)
- Patent #
- 10,107,488
- Care Instructions
- Warranty
- 1-Year
